Woven Fiberglass Insulation Tape

Non-adhesive woven fiberglass tape in thin wrapping and heavy packing formats for localized thermal and electrical assemblies.

  • Non-adhesive woven tape
  • 0.1–5 mm listed gauges
  • Multiple widths and roll lengths
Request a Quote -> Custom Size ->
Product Overview

Woven Fiberglass Insulation Tape Supplier

The narrow weave follows pipes and cables without cutting strips from a full roll. Thickness sets the build at overlaps, while width determines how quickly a surface can be covered. Keep the selected glass type explicit where the tape forms part of an electrical insulation system.

Technical Specifications

Product Parameters

Material and construction Woven E-glass or C-glass fiber
Standard formats Dense E-glass; 0.1 mm × 15 mm × 50 m; Dense E-glass; 0.1 mm × 20 mm × 50 m; Dense E-glass; 0.1 mm × 25 mm × 50 m; 22 listed formats
Ordering model HT-031
Price Request a Quote
Construction options Non-adhesive woven tape; 0.1–5 mm listed gauges; Multiple widths and roll lengths
MOQ Quoted by the selected supply unit and quantity
Packaging Rolls protected on cores; cut sheets separated and packed flat or rolled to suit the material.
Models & Available Formats

Available Stock Specifications

Choose a listed specification and quantity for a quotation. Dimensions, material construction and pack formats are shown by model.

Request Model Quote
SKU / Model Available Specification Material Supply Format Price
HT-031-P001 Dense E-glass; 0.1 mm × 15 mm × 50 m E-glass woven tape Roll / cut length Request a Quote
HT-031-P002 Dense E-glass; 0.1 mm × 20 mm × 50 m E-glass woven tape Roll / cut length Request a Quote
HT-031-P003 Dense E-glass; 0.1 mm × 25 mm × 50 m E-glass woven tape Roll / cut length Request a Quote
HT-031-P004 Dense E-glass; 0.1 mm × 30 mm × 50 m E-glass woven tape Roll / cut length Request a Quote
HT-031-P005 Dense E-glass; 0.1 mm × 50 mm × 50 m E-glass woven tape Roll / cut length Request a Quote
HT-031-P006 Dense E-glass; 0.1 mm × 100 mm × 50 m E-glass woven tape Roll / cut length Request a Quote
HT-031-P007 C-glass; 0.17 mm × 20 mm × 30 m C-glass woven tape Roll / cut length Request a Quote
HT-031-P008 C-glass; 0.17 mm × 25 mm × 30 m C-glass woven tape Roll / cut length Request a Quote
HT-031-P009 C-glass; 0.17 mm × 30 mm × 30 m C-glass woven tape Roll / cut length Request a Quote
HT-031-P010 C-glass; 0.17 mm × 50 mm × 30 m C-glass woven tape Roll / cut length Request a Quote
HT-031-P011 C-glass; 0.17 mm × 100 mm × 30 m C-glass woven tape Roll / cut length Request a Quote
HT-031-P012 C-glass; 0.17 mm × 150 mm × 30 m C-glass woven tape Roll / cut length Request a Quote
HT-031-P013 Heavy gauge; 3 mm × 20 mm × 30 m Woven E-glass or C-glass fiber Roll / cut length Request a Quote
HT-031-P014 Heavy gauge; 3 mm × 25 mm × 30 m Woven E-glass or C-glass fiber Roll / cut length Request a Quote
HT-031-P015 Heavy gauge; 3 mm × 30 mm × 30 m Woven E-glass or C-glass fiber Roll / cut length Request a Quote
HT-031-P016 Heavy gauge; 3 mm × 38 mm × 30 m Woven E-glass or C-glass fiber Roll / cut length Request a Quote
HT-031-P017 Heavy gauge; 3 mm × 50 mm × 30 m Woven E-glass or C-glass fiber Roll / cut length Request a Quote
HT-031-P018 Heavy gauge; 3 mm × 75 mm × 30 m Woven E-glass or C-glass fiber Roll / cut length Request a Quote
HT-031-P019 Heavy gauge; 3 mm × 80 mm × 30 m Woven E-glass or C-glass fiber Roll / cut length Request a Quote
HT-031-P020 Heavy gauge; 3 mm × 100 mm × 30 m Woven E-glass or C-glass fiber Roll / cut length Request a Quote
HT-031-P021 Heavy gauge; 5 mm × 30 mm × 30 m Woven E-glass or C-glass fiber Roll / cut length Request a Quote
HT-031-P022 Heavy gauge; 5 mm × 50 mm × 30 m Woven E-glass or C-glass fiber Roll / cut length Request a Quote

Note: Each line identifies a specification for quotation. Pricing covers the selected format, quantity, packing and delivery schedule.

Send specification for quotation ->
Applications

Typical Applications

  • Pipe insulation wrapping
  • Electrical winding separation
  • Equipment heat protection
Customization Options

Woven Fiberglass Insulation Tape Ordering Options

Send Requirement ->

For Woven Fiberglass Insulation Tape, specify finished thickness, width, cut outline and the required quantity.

  • Dimensions and construction Specify finished thickness, width, cut outline and the required quantity.
  • Material Woven E-glass or C-glass fiber
  • Supply and packing Rolls protected on cores; cut sheets separated and packed flat or rolled to suit the material.
FAQ

Frequently Asked Questions

Which thickness and roll formats are listed for woven fiberglass tape?

The table includes dense E-glass tape at 0.1 mm thickness in 50 m rolls, C-glass tape at 0.17 mm in 30 m rolls, and heavy-gauge 3 mm or 5 mm formats in 30 m rolls. Width options depend on the selected construction.

Is this woven fiberglass tape adhesive-backed?

The construction is explicitly described as non-adhesive woven tape. E-glass and C-glass entries are separately labelled; include the glass type as well as width and thickness when choosing a SKU.

What material is used for Woven Fiberglass Insulation Tape?

The specified material is woven E-glass or C-glass fiber.

What should I include in a quotation request?

For model HT-031, send the selected SKU and order quantity. Include glass type, thickness, tape width and listed roll length. Pricing is by quotation for the selected specification and quantity.
