Heat Set Braided Fiberglass Sleeving

Uncoated heat-set fiberglass sleeving in 0.5–35 mm listed diameters for wire protection and thermal separation.

  • Stabilized braided tube
  • Small and large sleeve diameters
  • 50–200 m listed roll formats
Request a Quote -> Custom Size ->
Product Overview

Heat Set Braided Fiberglass Sleeving Supplier

Heat setting stabilizes the braid so the tube retains a usable form during cutting and fitting. This uncoated construction is selected for its textile sleeve structure. Keep loose cut fibers away from terminals and select diameter from the finished conductor bundle rather than the copper alone.

Technical Specifications

Product Parameters

Material and construction Heat-set braided fiberglass
Standard formats 0.5 mm 200 m / roll; 1 mm 100 m / roll; 1.5 mm 100 m / roll; 22 listed formats
Ordering model HT-026
Price Request a Quote
Construction options Stabilized braided tube; Small and large sleeve diameters; 50–200 m listed roll formats
MOQ Quoted by the selected supply unit and quantity
Packaging Cut pieces protected from deformation and packed in cartons.
Models & Available Formats

Available Stock Specifications

Choose a listed specification and quantity for a quotation. Dimensions, material construction and pack formats are shown by model.

Request Model Quote
SKU / Model Available Specification Material Supply Format Price
HT-026-P001 0.5 mm 200 m / roll Heat-set braided fiberglass Roll / cut length Request a Quote
HT-026-P002 1 mm 100 m / roll Heat-set braided fiberglass Roll / cut length Request a Quote
HT-026-P003 1.5 mm 100 m / roll Heat-set braided fiberglass Roll / cut length Request a Quote
HT-026-P004 2 mm 100 m / roll Heat-set braided fiberglass Roll / cut length Request a Quote
HT-026-P005 2.5 mm 100 m / roll Heat-set braided fiberglass Roll / cut length Request a Quote
HT-026-P006 3 mm 100 m / roll Heat-set braided fiberglass Roll / cut length Request a Quote
HT-026-P007 4 mm 100 m / roll Heat-set braided fiberglass Roll / cut length Request a Quote
HT-026-P008 5 mm 100 m / roll Heat-set braided fiberglass Roll / cut length Request a Quote
HT-026-P009 6 mm 100 m / roll Heat-set braided fiberglass Roll / cut length Request a Quote
HT-026-P010 8 mm 50 m / roll Heat-set braided fiberglass Roll / cut length Request a Quote
HT-026-P011 9 mm 50 m / roll Heat-set braided fiberglass Roll / cut length Request a Quote
HT-026-P012 10 mm 50 m / roll Heat-set braided fiberglass Roll / cut length Request a Quote
HT-026-P013 12 mm 50 m / roll Heat-set braided fiberglass Roll / cut length Request a Quote
HT-026-P014 14 mm 50 m / roll Heat-set braided fiberglass Roll / cut length Request a Quote
HT-026-P015 16 mm 50 m / roll Heat-set braided fiberglass Roll / cut length Request a Quote
HT-026-P016 18 mm 50 m / roll Heat-set braided fiberglass Roll / cut length Request a Quote
HT-026-P017 20 mm 50 m / roll Heat-set braided fiberglass Roll / cut length Request a Quote
HT-026-P018 22 mm 50 m / roll Heat-set braided fiberglass Roll / cut length Request a Quote
HT-026-P019 25 mm 50 m / roll Heat-set braided fiberglass Roll / cut length Request a Quote
HT-026-P020 28 mm 50 m / roll Heat-set braided fiberglass Roll / cut length Request a Quote
HT-026-P021 30 mm 50 m / roll Heat-set braided fiberglass Roll / cut length Request a Quote
HT-026-P022 35 mm 50 m / roll Heat-set braided fiberglass Roll / cut length Request a Quote

Note: Each line identifies a specification for quotation. Pricing covers the selected format, quantity, packing and delivery schedule.

Send specification for quotation ->
Applications

Typical Applications

  • Heater lead protection
  • Thermal wire separation
  • Equipment harness covering
Customization Options

Heat Set Braided Fiberglass Sleeving Ordering Options

Send Requirement ->

For Heat Set Braided Fiberglass Sleeving, specify finished thickness, width, cut outline and the required quantity.

  • Dimensions and construction Specify finished thickness, width, cut outline and the required quantity.
  • Material Heat-set braided fiberglass
  • Supply and packing Cut pieces protected from deformation and packed in cartons.
FAQ

Frequently Asked Questions

Which diameter and roll-length combinations are listed for heat-set sleeving?

The 0.5 mm entry is 200 m per roll. Listed 1–6 mm diameters use 100 m rolls, and listed 8–35 mm diameters use 50 m rolls. These are discrete diameter entries, so select the exact size in the table.

Is this heat-set sleeving listed as varnish-coated material?

The material is heat-set braided fiberglass and the construction is a stabilized braided tube. A varnish coating is not identified in these parameters; specify heat-set construction when selecting this product.

What material is used for Heat Set Braided Fiberglass Sleeving?

The specified material is heat-set braided fiberglass.

What should I include in a quotation request?

For model HT-026, send the selected SKU and order quantity. Include sleeve diameter, listed roll length and number of rolls. Pricing is by quotation for the selected specification and quantity.
