FR-900 PTFE Sealing Belt Sets

15 mm-wide PTFE sealing belt sets for FR-900-style continuous sealers, with multiple loop lengths and pack quantities.

  • 15 mm nominal width
  • Multiple loop circumferences
  • 10-, 20- and 50-belt packs
Request a Quote -> Custom Size ->
Product Overview

FR-900 PTFE Sealing Belt Sets Supplier

These narrow loops carry film through the heated sealing zone and provide a release surface. FR-900 is a machine-family reference rather than a universal fit. Match the old belt circumference, width, tensioning travel and construction before selecting a replacement pack.

Technical Specifications

Product Parameters

Material and construction PTFE-coated fiberglass belt
Standard formats Circumference 750 mm × width 15 mm × 10 pieces; Circumference 770 mm × width 15 mm × 10 pieces; Circumference 810 mm × width 15 mm × 10 pieces; 29 listed formats
Ordering model HT-007
Price Request a Quote
Construction options 15 mm nominal width; Multiple loop circumferences; 10-, 20- and 50-belt packs
MOQ Quoted by the selected supply unit and quantity
Packaging Coils or matched sets protected against sharp bends and packed in cartons.
Models & Available Formats

Available Stock Specifications

Choose a listed specification and quantity for a quotation. Dimensions, material construction and pack formats are shown by model.

Request Model Quote
SKU / Model Available Specification Material Supply Format Price
HT-007-001 Circumference 750 mm × width 15 mm × 10 pieces PTFE-coated fiberglass belt Listed pack Request a Quote
HT-007-002 Circumference 770 mm × width 15 mm × 10 pieces PTFE-coated fiberglass belt Listed pack Request a Quote
HT-007-003 Circumference 810 mm × width 15 mm × 10 pieces PTFE-coated fiberglass belt Listed pack Request a Quote
HT-007-004 Circumference 1010 mm × width 15 mm × 10 pieces PTFE-coated fiberglass belt Listed pack Request a Quote
HT-007-005 Circumference 1210 mm × width 15 mm × 10 pieces PTFE-coated fiberglass belt Listed pack Request a Quote
HT-007-006 Circumference 1120 mm × width 15 mm × 10 pieces PTFE-coated fiberglass belt Listed pack Request a Quote
HT-007-007 Circumference 1170 mm × width 15 mm × 10 pieces PTFE-coated fiberglass belt Listed pack Request a Quote
HT-007-008 Circumference 1100 mm × width 15 mm × 10 pieces PTFE-coated fiberglass belt Listed pack Request a Quote
HT-007-009 Circumference 750 mm × width 15 mm; pack of 50 belts PTFE-coated fiberglass belt Pack of 50 belts Request a Quote
HT-007-010 Circumference 770 mm × width 15mm20 pieces PTFE-coated fiberglass belt Listed pack Request a Quote
HT-007-011 Circumference 770 mm × width 15 mm; pack of 50 belts PTFE-coated fiberglass belt Pack of 50 belts Request a Quote
HT-007-012 Circumference 810 mm × width 15mm20 pieces PTFE-coated fiberglass belt Listed pack Request a Quote
HT-007-013 Circumference 810 mm × width 15 mm; pack of 50 belts PTFE-coated fiberglass belt Pack of 50 belts Request a Quote
HT-007-014 Circumference 1010 mm × width 15mm20 pieces PTFE-coated fiberglass belt Listed pack Request a Quote
HT-007-015 Circumference 1010 mm × width 15 mm; pack of 50 belts PTFE-coated fiberglass belt Pack of 50 belts Request a Quote
HT-007-016 Circumference 1210 mm × width 15mm20 pieces PTFE-coated fiberglass belt Listed pack Request a Quote
HT-007-017 Circumference 1210 mm × width 15 mm; pack of 50 belts PTFE-coated fiberglass belt Pack of 50 belts Request a Quote
HT-007-018 Circumference 1120 mm × width 15mm20 pieces PTFE-coated fiberglass belt Listed pack Request a Quote
HT-007-019 Circumference 1120 mm × width 15 mm; pack of 50 belts PTFE-coated fiberglass belt Pack of 50 belts Request a Quote
HT-007-020 Heavy-duty variant; × Circumference 750 mm × width 15 mm × per 10 pieces PTFE-coated fiberglass belt Listed pack Request a Quote
HT-007-021 Heavy-duty variant; × Circumference 770 mm × width 15 mm × per 10 pieces PTFE-coated fiberglass belt Listed pack Request a Quote
HT-007-022 Heavy-duty variant; × Circumference 810 mm × width 15 mm × per 10 pieces PTFE-coated fiberglass belt Listed pack Request a Quote
HT-007-023 Heavy-duty variant; × Circumference 1000 mm × width 15 mm per 10 pieces PTFE-coated fiberglass belt Listed pack Request a Quote
HT-007-024 Heavy-duty variant; × Circumference 1010 mm × width 15 mm × per 10 pieces PTFE-coated fiberglass belt Listed pack Request a Quote
HT-007-025 Heavy-duty variant; × Circumference 1100 mm × width 15 mm × per 10 pieces PTFE-coated fiberglass belt Listed pack Request a Quote
HT-007-026 Heavy-duty variant; × Circumference 1120 mm × width 15 mm × per 10 pieces PTFE-coated fiberglass belt Listed pack Request a Quote
HT-007-027 Heavy-duty variant; × Circumference 1210 mm × width 15 mm × per 10 pieces PTFE-coated fiberglass belt Listed pack Request a Quote
HT-007-028 Heavy-duty variant; × Circumference 1350 mm × width 15 mm × per 10 pieces PTFE-coated fiberglass belt Listed pack Request a Quote
HT-007-029 Heavy-duty variant; × Circumference 1366 mm × width 15 mm × per 10 pieces PTFE-coated fiberglass belt Listed pack Request a Quote

Note: Each line identifies a specification for quotation. Pricing covers the selected format, quantity, packing and delivery schedule.

Send specification for quotation ->
Applications

Typical Applications

  • Continuous band sealers
  • Packaging line maintenance
  • Sealing belt replacement
Customization Options

FR-900 PTFE Sealing Belt Sets Ordering Options

Send Requirement ->

For FR-900 PTFE Sealing Belt Sets, specify width, circumference, joint and machine layout.

  • Dimensions and construction Specify width, circumference, joint and machine layout.
  • Material PTFE-coated fiberglass belt
  • Supply and packing Coils or matched sets protected against sharp bends and packed in cartons.
FAQ

Frequently Asked Questions

Which width and loop circumferences are listed for FR-900 sealing belts?

The nominal width is 15 mm. Listed circumferences include 750, 770, 810, 1010, 1100, 1120, 1170 and 1210 mm, with additional heavy-duty entries such as 1000, 1350 and 1366 mm. Select by the stated circumference and variant.

Are FR-900 belt packs available in different quantities?

Yes. The table includes packs of 10, 20 and 50 belts, with the quantity depending on the selected circumference. Heavy-duty entries are separately listed as 10-piece packs. The pack quantity is part of the SKU specification.

What material is used for FR-900 PTFE Sealing Belt Sets?

The specified material is PTFE-coated fiberglass belt.

What should I include in a quotation request?

For model HT-007, send the selected SKU and order quantity. Include loop circumference, 15 mm width, standard or heavy-duty variant and number of packs. Pricing is by quotation for the selected specification and quantity.
