Flexible Electrical Insulation Pressboard

Flexible brown electrical pressboard and unlaminated paper formats for transformer barriers, liners and shaped separators.

  • Paper and pressboard thicknesses
  • Unlaminated thin formats
  • Large-area sheets for conversion
Request a Quote -> Custom Size ->
Product Overview

Flexible Electrical Insulation Pressboard Supplier

Thin paper wraps around compact shapes; heavier pressboard forms barriers and spacers with greater body. The listed sheet formats differ in both area and thickness. Select a sheet large enough for the blank, with bending allowance for folded parts rather than ordering from thickness alone.

Technical Specifications

Product Parameters

Material and construction Cellulose electrical insulation paper and pressboard
Standard formats Flexible pressboard; 2 mm × 1 m × 2 m; Flexible pressboard; 1 mm × 1 m × 2 m; Flexible pressboard; 0.8 mm × 1 m × 2 m; 11 listed formats
Ordering model HT-012
Price Request a Quote
Construction options Paper and pressboard thicknesses; Unlaminated thin formats; Large-area sheets for conversion
MOQ Quoted by the selected supply unit and quantity
Packaging Cut pieces protected from deformation and packed in cartons.
Models & Available Formats

Available Stock Specifications

Choose a listed specification and quantity for a quotation. Dimensions, material construction and pack formats are shown by model.

Request Model Quote
SKU / Model Available Specification Material Supply Format Price
HT-012-P001 Flexible pressboard; 2 mm × 1 m × 2 m Cellulose electrical insulation paper and pressboard Pack / cut part Request a Quote
HT-012-P002 Flexible pressboard; 1 mm × 1 m × 2 m Cellulose electrical insulation paper and pressboard Pack / cut part Request a Quote
HT-012-P003 Flexible pressboard; 0.8 mm × 1 m × 2 m Cellulose electrical insulation paper and pressboard Pack / cut part Request a Quote
HT-012-P004 Flexible pressboard; 0.3 mm × 1 m × 1.4 m Cellulose electrical insulation paper and pressboard Pack / cut part Request a Quote
HT-012-P005 Flexible pressboard; 0.5 mm × 80 cm × 1.15 m Cellulose electrical insulation paper and pressboard Pack / cut part Request a Quote
HT-012-P006 Flexible pressboard; 0.3 mm × 80 cm × 1.15 m Cellulose electrical insulation paper and pressboard Pack / cut part Request a Quote
HT-012-P007 Flexible pressboard; 0.5 mm × 1 m × 1.4 m Cellulose electrical insulation paper and pressboard Pack / cut part Request a Quote
HT-012-P008 Unlaminated; 0.1 mm thickness × 1 m width × 1 m length Cellulose electrical insulation paper and pressboard Roll / cut length Request a Quote
HT-012-P009 Unlaminated; 0.2 mm thickness × 1 m width × 1 m length Cellulose electrical insulation paper and pressboard Roll / cut length Request a Quote
HT-012-P010 Unlaminated; 0.3 mm thickness × 1 m width × 1 m length Cellulose electrical insulation paper and pressboard Roll / cut length Request a Quote
HT-012-P011 Unlaminated; 0.5 mm thickness × 1 m width × 1 m length Cellulose electrical insulation paper and pressboard Roll / cut length Request a Quote

Note: Each line identifies a specification for quotation. Pricing covers the selected format, quantity, packing and delivery schedule.

Send specification for quotation ->
Applications

Typical Applications

  • Transformer barriers
  • Electrical separators
  • Folded equipment liners
Customization Options

Flexible Electrical Insulation Pressboard Ordering Options

Send Requirement ->

For Flexible Electrical Insulation Pressboard, specify finished thickness, width, cut outline and the required quantity.

  • Dimensions and construction Specify finished thickness, width, cut outline and the required quantity.
  • Material Cellulose electrical insulation paper and pressboard
  • Supply and packing Cut pieces protected from deformation and packed in cartons.
FAQ

Frequently Asked Questions

Which flexible pressboard sheet sizes are listed?

The table includes 1 m × 2 m pressboard at 0.8, 1 and 2 mm thicknesses, plus 1 m × 1.4 m and 80 cm × 1.15 m sheets in selected 0.3 and 0.5 mm gauges. Select the complete thickness-and-sheet-size entry.

Does the table include thin unlaminated insulation paper?

Yes. Separate unlaminated entries are listed at 0.1, 0.2, 0.3 and 0.5 mm thickness, each with 1 m width × 1 m length. These entries are distinct from the flexible pressboard sheets.

What material is used for Flexible Electrical Insulation Pressboard?

The specified material is cellulose electrical insulation paper and pressboard.

What should I include in a quotation request?

For model HT-012, send the selected SKU and order quantity. Include pressboard or unlaminated paper construction, thickness and sheet dimensions. Pricing is by quotation for the selected specification and quantity.
