Fiberglass Pipe Wrap Reinforcement Cloth

Fiberglass reinforcement wraps in defined weave densities, strip widths and roll lengths for pipe coating and composite repair.

  • Narrow pipe-wrap rolls
  • Multiple weave densities
  • Wide reinforcement cloth options
Request a Quote -> Custom Size ->
Product Overview

Fiberglass Pipe Wrap Reinforcement Cloth Supplier

The fabric reinforces a coating or resin system; it is not a complete corrosion barrier on its own. Narrow rolls follow pipe contours and wider cloth covers larger surfaces. Match weave density to resin wet-out, overlap and the intended laminate build so the installed layer remains continuous.

Technical Specifications

Product Parameters

Material and construction Woven fiberglass fabric
Standard formats Weave density 8 × 8 width 22 cm length 40 m / roll; Weave density 8 × 8 width 25 cm length 60 m / roll; Weave density 8 × 8 width 44 cm length 40 m / roll; 24 listed formats
Ordering model HT-046
Price Request a Quote
Construction options Narrow pipe-wrap rolls; Multiple weave densities; Wide reinforcement cloth options
MOQ Quoted by the selected supply unit and quantity
Packaging Coils or matched sets protected against sharp bends and packed in cartons.
Models & Available Formats

Available Stock Specifications

Choose a listed specification and quantity for a quotation. Dimensions, material construction and pack formats are shown by model.

Request Model Quote
SKU / Model Available Specification Material Supply Format Price
HT-046-P001 Weave density 8 × 8 width 22 cm length 40 m / roll Woven fiberglass fabric Roll / cut length Request a Quote
HT-046-P002 Weave density 8 × 8 width 25 cm length 60 m / roll Woven fiberglass fabric Roll / cut length Request a Quote
HT-046-P003 Weave density 8 × 8 width 44 cm length 40 m / roll Woven fiberglass fabric Roll / cut length Request a Quote
HT-046-P004 Weave density 8 × 8 width 88 cm length 40 m / roll Woven fiberglass fabric Roll / cut length Request a Quote
HT-046-P005 Weave density 6 × 6 width 100 cm length 60 m / roll Woven fiberglass fabric Roll / cut length Request a Quote
HT-046-P006 Weave density 10 × 10 width 22 cm length 40 m / roll Woven fiberglass fabric Roll / cut length Request a Quote
HT-046-P007 Weave density 10 × 10 width 44 cm length 40 m / roll Woven fiberglass fabric Roll / cut length Request a Quote
HT-046-P008 Weave density 10 × 10 width 88 cm length 40 m / roll Woven fiberglass fabric Roll / cut length Request a Quote
HT-046-P009 Weave density 10 × 10 width 100 cm length 60 m / roll Woven fiberglass fabric Roll / cut length Request a Quote
HT-046-P010 Weave density 12 × 12 width 22 cm length 40 m / roll Woven fiberglass fabric Roll / cut length Request a Quote
HT-046-P011 Weave density 12 × 12 width 44 cm length 40 m / roll Woven fiberglass fabric Roll / cut length Request a Quote
HT-046-P012 Weave density 12 × 12 width 88 cm length 40 m / roll Woven fiberglass fabric Roll / cut length Request a Quote
HT-046-P013 Weave density 12 × 12 width 100 cm length 50 m / roll Woven fiberglass fabric Roll / cut length Request a Quote
HT-046-P014 Weave density 14 × 14 width 25 cm length 50 m / roll Woven fiberglass fabric Roll / cut length Request a Quote
HT-046-P015 Weave density 14 × 14 width 50 cm length 50 m / roll Woven fiberglass fabric Roll / cut length Request a Quote
HT-046-P016 Weave density 14 × 14 width 100 cm length 90 m / roll Woven fiberglass fabric Roll / cut length Request a Quote
HT-046-P017 Weave density 16 × 16 width 100 cm length 50 m / roll Woven fiberglass fabric Roll / cut length Request a Quote
HT-046-P018 Standard weave; 12 × 12 width 25 cm length 50 m / roll Woven fiberglass fabric Roll / cut length Request a Quote
HT-046-P019 Standard weave; 12 × 12 width 50 cm length 50 m / roll Woven fiberglass fabric Roll / cut length Request a Quote
HT-046-P020 Standard weave; 12 × 12 width 105 cm length 100 m / roll Woven fiberglass fabric Roll / cut length Request a Quote
HT-046-P021 Standard weave; 12 × 12 width 125 cm length 100 m / roll Woven fiberglass fabric Roll / cut length Request a Quote
HT-046-P022 0.2 thickness 02 cloth width 28 cm length 95 m / roll Woven fiberglass fabric Roll / cut length Request a Quote
HT-046-P023 0.2 thickness 02 cloth width 45 cm length 95 m / roll Woven fiberglass fabric Roll / cut length Request a Quote
HT-046-P024 0.2 thickness 02 cloth width 90 cm length 95 m / roll Woven fiberglass fabric Roll / cut length Request a Quote

Note: Each line identifies a specification for quotation. Pricing covers the selected format, quantity, packing and delivery schedule.

Send specification for quotation ->
Applications

Typical Applications

  • Pipe coating reinforcement
  • Composite repair layers
  • Resin-backed equipment wraps
Customization Options

Fiberglass Pipe Wrap Reinforcement Cloth Ordering Options

Send Requirement ->

For Fiberglass Pipe Wrap Reinforcement Cloth, specify finished thickness, width, cut outline and the required quantity.

  • Dimensions and construction Specify finished thickness, width, cut outline and the required quantity.
  • Material Woven fiberglass fabric
  • Supply and packing Coils or matched sets protected against sharp bends and packed in cartons.
FAQ

Frequently Asked Questions

Which weave densities are listed for fiberglass pipe-wrap cloth?

The table includes weave densities such as 6 × 6, 8 × 8, 10 × 10, 12 × 12, 14 × 14 and 16 × 16. Each entry pairs the weave description with a width and roll length; those combinations differ by SKU.

Are narrow pipe-wrap rolls and wider cloth formats both listed?

Yes. Examples include 8 × 8 weave at 22 cm width × 40 m length and 6 × 6 weave at 100 cm width × 60 m length. Separate standard-weave entries include 105 and 125 cm widths. Select the full weave, width and length combination.

What material is used for Fiberglass Pipe Wrap Reinforcement Cloth?

The specified material is woven fiberglass fabric.

What should I include in a quotation request?

For model HT-046, send the selected SKU and order quantity. Include weave density or cloth designation, width and listed roll length. Pricing is by quotation for the selected specification and quantity.
