E-Glass Woven Insulation Fabric

E-glass woven fabric in fine and heavier gauges for electrical reinforcement, laminates and thermal protective assemblies.

  • Low-alkali E-glass
  • Thin and heavier weave formats
  • Roll and narrow-cut options
Request a Quote -> Custom Size ->
Product Overview

E-Glass Woven Insulation Fabric Supplier

The low-alkali glass construction suits applications that specify E-glass reinforcement. Thin dense cloth follows fine parts; heavier cloth builds thicker layers. Match the weave and finish to resin processing or the insulation design, and arrange cut edges to minimize loose fibers at assembly points.

Technical Specifications

Product Parameters

Material and construction Low-alkali E-glass fiber
Standard formats Dense E-glass; 0.06 mm thickness × 1 m width / per meter; Dense E-glass; 0.06 mm thickness × 1.27 m/ per meter; width; Dense E-glass; 0.1 mm thickness × 0.9 m width / per meter; 33 listed formats
Ordering model HT-032
Price Request a Quote
Construction options Low-alkali E-glass; Thin and heavier weave formats; Roll and narrow-cut options
MOQ Quoted by the selected supply unit and quantity
Packaging Rolls protected on cores; cut sheets separated and packed flat or rolled to suit the material.
Models & Available Formats

Available Stock Specifications

Choose a listed specification and quantity for a quotation. Dimensions, material construction and pack formats are shown by model.

Request Model Quote
SKU / Model Available Specification Material Supply Format Price
HT-032-P001 Dense E-glass; 0.06 mm thickness × 1 m width / per meter Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P002 Dense E-glass; 0.06 mm thickness × 1.27 m/ per meter; width Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P003 Dense E-glass; 0.1 mm thickness × 0.9 m width / per meter Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P004 Dense E-glass; 0.1 mm thickness × 1 m width / per meter Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P005 Dense E-glass; 0.1 mm thickness × 1.27 m width / per meter Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P006 Dense E-glass; 0.14 mm thickness × 1 m width / per meter Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P007 Dense E-glass; 0.14 mm thickness × 1.27 m width / per meter Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P008 Dense E-glass; 0.18 mm thickness × 1 m width / per meter Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P009 Dense E-glass; 0.18 mm thickness × 1.27 m width / per meter Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P010 Dense E-glass; 0.3 mm × 1 m/ per meter Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P011 Dense E-glass; 0.4 mm thickness × 1 m width / per meter Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P012 Dense E-glass; 0.45 mm thickness × 1 m width / per meter Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P013 Dense E-glass; 0.5 mm thickness × 1 m width / per meter Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P014 Dense E-glass; 0.8 mm thickness × 1 m width / per meter Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P015 Dense E-glass; 0.8 mm thickness × 330 mm width / per meter Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P016 Dense E-glass; 1 mm thickness × 1 m width / per meter Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P017 Dense E-glass; 0.2 mm thickness × 1 m width / per meter Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P018 Dense E-glass; 0.2 mm thickness × 1.27 m width / per meter Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P019 0.5 mm thickness × 1 m width / per meter Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P020 0.5 mm thickness × 1.2 m width / per meter Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P021 0.8 mm thickness × 1 m width / per meter Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P022 1 mm thickness × 1 m width / per meter Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P023 1.5 mm thickness × 1 m width / per meter Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P024 2 mm thickness × 1 m width / per meter Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P025 3 mm thickness × 1 m width / per meter Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P026 5 mm thickness × 1 m width / per meter Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P027 Foil-faced fiberglass; 0.5 mm thickness × 1 m width / per meter Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P028 0.5 mm thickness × 1.5 m width / per meter Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P029 0.5 mm thickness × 1.8 m width / per meter Low-alkali E-glass fiber Roll / cut length Request a Quote
HT-032-P030 Ceramic fiber fabric; 2 mm thickness × 1 m width / per meter Ceramic fiber fabric Roll / cut length Request a Quote
HT-032-P031 Ceramic fiber fabric; 3 mm thickness × 1 m width / per meter Ceramic fiber fabric Roll / cut length Request a Quote
HT-032-P032 Ceramic fiber fabric; 5 mm thickness × 1 m width / per meter Ceramic fiber fabric Roll / cut length Request a Quote
HT-032-P034 0.1 mm thickness x230 mm width × 10 m Low-alkali E-glass fiber Roll / cut length Request a Quote

Note: Each line identifies a specification for quotation. Pricing covers the selected format, quantity, packing and delivery schedule.

Send specification for quotation ->
Applications

Typical Applications

  • Electrical laminates
  • Composite reinforcement
  • Equipment insulation covers
Customization Options

E-Glass Woven Insulation Fabric Ordering Options

Send Requirement ->

For E-Glass Woven Insulation Fabric, specify finished thickness, width, cut outline and the required quantity.

  • Dimensions and construction Specify finished thickness, width, cut outline and the required quantity.
  • Material Low-alkali E-glass fiber
  • Supply and packing Rolls protected on cores; cut sheets separated and packed flat or rolled to suit the material.
FAQ

Frequently Asked Questions

Which E-glass fabric widths and gauges are listed?

Dense E-glass entries include selected gauges from 0.06 to 1 mm, with widths such as 0.9, 1 and 1.27 m. A narrow 0.8 mm × 330 mm entry is also listed. The table contains additional heavier and alternative constructions, so check each full description.

Are all entries in this fabric table the same E-glass construction?

No. The table separately identifies foil-faced fiberglass and ceramic-fiber fabric, alongside dense E-glass entries. Those labelled alternatives should be requested by their own SKU and construction rather than assumed to be ordinary E-glass cloth.

What material is used for E-Glass Woven Insulation Fabric?

The specified material is low-alkali E-glass fiber.

What should I include in a quotation request?

For model HT-032, send the selected SKU and order quantity. Include selected fabric construction, thickness, width and required length. Pricing is by quotation for the selected specification and quantity.
