Black PET Electrical Insulation Film

Black PET film in 0.05–0.5 mm listed formats for opaque barriers, cut separators and equipment-facing liners.

  • Opaque black film
  • Multiple film thicknesses
  • 480, 610 and 1000 mm widths
Request a Quote -> Custom Size ->
Product Overview

Black PET Electrical Insulation Film Supplier

The black polyester face conceals underlying parts where an opaque layer is needed. Thin film follows compact shapes while heavier gauges provide more body. Specify surface finish, thickness and the required outline for converted parts; black color alone does not establish antistatic or conductive properties.

Technical Specifications

Product Parameters

Material and construction Black PET polyester film
Standard formats 0.25 mm thickness × 1 m width / per meter; 0.5 mm thickness × 61 cm width / per meter; 0.188 mm thickness × 1 m width / per meter; 9 listed formats
Ordering model HT-086
Price Request a Quote
Construction options Opaque black film; Multiple film thicknesses; 480, 610 and 1000 mm widths
MOQ Quoted by the selected supply unit and quantity
Packaging Rolls protected on cores; cut sheets separated and packed flat or rolled to suit the material.
Models & Available Formats

Available Stock Specifications

Choose a listed specification and quantity for a quotation. Dimensions, material construction and pack formats are shown by model.

Request Model Quote
SKU / Model Available Specification Material Supply Format Price
HT-086-P001 0.25 mm thickness × 1 m width / per meter Black PET polyester film Roll / cut length Request a Quote
HT-086-P002 0.5 mm thickness × 61 cm width / per meter Black PET polyester film Roll / cut length Request a Quote
HT-086-P003 0.188 mm thickness × 1 m width / per meter Black PET polyester film Roll / cut length Request a Quote
HT-086-P004 0.075 mm thickness × 1 m width / per meter Black PET polyester film Roll / cut length Request a Quote
HT-086-P005 0.1 mm thickness × 1 m width / per meter Black PET polyester film Roll / cut length Request a Quote
HT-086-P006 0.15 mm thickness × 1 m width / per meter Black PET polyester film Roll / cut length Request a Quote
HT-086-P007 0.05 mm thickness × 1 m width / per meter Black PET polyester film Roll / cut length Request a Quote
HT-086-P008 0.1 mm thickness × 48 cm width / per meter Black PET polyester film Roll / cut length Request a Quote
HT-086-P009 0.3 mm thickness × 1 m width / per meter Black PET polyester film Roll / cut length Request a Quote

Note: Each line identifies a specification for quotation. Pricing covers the selected format, quantity, packing and delivery schedule.

Send specification for quotation ->
Applications

Typical Applications

  • Opaque electrical barriers
  • Equipment separator films
  • Converted black liners
Customization Options

Black PET Electrical Insulation Film Ordering Options

Send Requirement ->

For Black PET Electrical Insulation Film, specify finished thickness, width, cut outline and the required quantity.

  • Dimensions and construction Specify finished thickness, width, cut outline and the required quantity.
  • Material Black PET polyester film
  • Supply and packing Rolls protected on cores; cut sheets separated and packed flat or rolled to suit the material.
FAQ

Frequently Asked Questions

Which black PET thickness-and-width pairs are listed?

Several entries are 1 m wide in gauges such as 0.05, 0.075, 0.1, 0.15, 0.188, 0.25 and 0.3 mm. Separate entries are 0.5 mm × 61 cm width and 0.1 mm × 48 cm width. All use a per-meter description.

Does the black PET parameter file state antistatic performance?

The parameters describe opaque black PET film and its dimensions, but do not state an antistatic rating or measured resistance. Include any static-control requirement for confirmation rather than inferring it from the black color.

What material is used for Black PET Electrical Insulation Film?

The specified material is black PET polyester film.

What should I include in a quotation request?

For model HT-086, send the selected SKU and order quantity. Include black PET gauge, width, meter quantity and any required electrical properties. Pricing is by quotation for the selected specification and quantity.
