Smooth Double Face PTFE Release Cloth

Smooth double-face PTFE cloth in multiple widths for moving release liners, heat press covers and non-stick separation panels.

  • Double-smooth face options
  • Narrow and wide roll formats
  • Marked woven alternatives
Request a Quote -> Custom Size ->
Product Overview

Smooth Double Face PTFE Release Cloth Supplier

A smooth face is useful where contact texture matters. This range includes several double-smooth formats as well as specifically marked woven variants. Select the finish on both faces where the cloth turns over rollers or contacts a workpiece on either side; specify thickness separately from finish.

Technical Specifications

Product Parameters

Material and construction PTFE-coated fiberglass fabric
Standard formats 0.13 mm × 45 cm width / per meter ( Smooth release face on both sides ) Brown; 0.13 mm × 55 cm/ per meter ( Smooth release face on both sides ) Brown; 0.08 mm × 1 m width / per meter ( Smooth release face on both sides ) Brown; 44 listed formats
Ordering model HT-060
Price Request a Quote
Construction options Double-smooth face options; Narrow and wide roll formats; Marked woven alternatives
MOQ Quoted by the selected supply unit and quantity
Packaging Rolls protected on cores; cut sheets separated and packed flat or rolled to suit the material.
Models & Available Formats

Available Stock Specifications

Choose a listed specification and quantity for a quotation. Dimensions, material construction and pack formats are shown by model.

Request Model Quote
SKU / Model Available Specification Material Supply Format Price
HT-060-P001 0.13 mm × 45 cm width / per meter ( Smooth release face on both sides ) Brown PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P002 0.13 mm × 55 cm/ per meter ( Smooth release face on both sides ) Brown PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P003 0.08 mm × 1 m width / per meter ( Smooth release face on both sides ) Brown PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P004 0.08 mm × 1.25 m width / per meter ( Smooth release face on both sides ) Brown PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P005 0.13 mm × 1 m width / per meter ( Smooth release face on both sides ) Brown PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P006 0.13 mm × 1.25 m width / per meter ( Smooth release face on both sides ) Brown PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P007 0.18 mm × 1.25 m width / per meter ( Smooth release face on both sides ) Brown PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P008 0.25 mm × 1 m width / per meter ( Smooth release face on both sides ) Brown PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P009 0.25 mm × 1.25 m width / per meter ( Smooth release face on both sides ) Brown PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P010 0.3 mm × 1 m width / per meter ( Smooth release face on both sides ) Brown PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P011 0.35 mm × 1 m width / per meter ( Smooth release face on both sides ) Brown PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P012 0.08 mm × 1 m width / per meter ( Smooth release face on both sides ) Brown PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P013 0.13 mm × 1 m width / per meter ( Smooth release face on both sides ) Brown PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P014 0.15 mm × 1 m width / per meter ( Smooth release face on both sides ) Brown PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P015 0.18 mm × 1 m width -/ per meter ( Smooth release face on both sides ) Brown PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P016 0.25 mm × 1 m width / per meter ( Smooth release face on both sides ) Brown PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P017 0.3 mm × 1 m width / per meter ( Smooth release face on both sides ) Brown PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P018 0.35 mm × 1 m width / per meter ( Smooth release face on both sides ) Brown PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P019 0.13 × 1.25 m width / per meter ( Smooth release face on both sides ) Brown PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P020 0.18 mm × 1 m width / per meter ( Smooth release face on both sides ) Brown PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P021 0.08 mm × 1 m width × 1 m length - Smooth on both sides White PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P022 0.08 mm × 1.25 m width × 1 m length - Smooth on both sides White PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P023 0.1 mm × 1.1 m width × 1 m length - Smooth on both sides White PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P024 0.1 mm × 1 m width × 1 m length - Smooth on both sides White PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P025 0.11 mm × 1.1 m width × 1 m length - Smooth on both sides White PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P026 0.11 mm × 1 m width × 1 m length - Smooth on both sides White PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P027 0.12 mm × 1 m width × 1 m length - Smooth on both sides White PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P028 0.12 mm × 1.1 m width × 1 m length - Smooth on both sides White PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P029 0.12 mm × 1.25 m width × 1 m length - Smooth on both sides White PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P030 0.13 mm × 1.1 m width × 1 m length - Smooth on both sides White PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P031 0.13 mm × 1 m width × 1 m length - Smooth on both sides White PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P032 0.13 mm × 1.25 m width × 1 m length - Smooth on both sides White PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P033 0.14 mm × 1 m width × 1 m length - Smooth on both sides White PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P034 0.14 mm × 1.25 m width × 1 m length - Smooth on both sides White PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P035 0.15 mm × 1 m width × 1 m length - Smooth on both sides White PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P036 0.15 mm × 1.25 m width × 1 m length - Smooth on both sides White PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P037 0.18 mm × 1.25 m width × 1 m length - Smooth on both sides White PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P038 0.2 mm × 1.25 m width × 1 m length - Smooth on both sides White PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P039 0.22 mm × 1 m width × 1 m length - Smooth on both sides White PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P040 0.22 mm × 1.25 m width × 1 m length - Smooth on both sides White PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P041 0.25 mm × 1 m width × 1 m length - Smooth on both sides White PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P042 0.25 mm × 1.25 m width × 1 m length - Smooth on both sides White PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P043 0.35 mm × 1.25 m width × 1 m length - Smooth on both sides White PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P044 0.08 mm × 1 m width × 1 m length - Textured weave Brown PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P045 0.12 mm × 1 m width × 1 m length - Textured weave Brown PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P046 0.15 mm × 1 m width × 1 m length - Textured weave Brown PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P047 0.18 mm × 1 m width × 1 m length - Textured weave Brown PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P048 0.25 mm × 1 m width × 1 m length - Textured weave Brown PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-060-P049 0.15 mm × 1.25 m width / per meter ( Smooth release face on both sides ) Brown PTFE-coated fiberglass fabric Roll / cut length Request a Quote

Note: Each line identifies a specification for quotation. Pricing covers the selected format, quantity, packing and delivery schedule.

Send specification for quotation ->
Applications

Typical Applications

  • Moving release liners
  • Heat press covers
  • Separation panels between parts
Customization Options

Smooth Double Face PTFE Release Cloth Ordering Options

Send Requirement ->

For Smooth Double Face PTFE Release Cloth, specify finished thickness, width, cut outline and the required quantity.

  • Dimensions and construction Specify finished thickness, width, cut outline and the required quantity.
  • Material PTFE-coated fiberglass fabric
  • Supply and packing Rolls protected on cores; cut sheets separated and packed flat or rolled to suit the material.
FAQ

Frequently Asked Questions

Which widths are listed for smooth double-face PTFE cloth?

Double-smooth entries include narrow 45 and 55 cm widths and wider formats such as 1, 1.1 and 1.25 m. The available thickness and color depend on the selected width and SKU.

Are all entries in this table smooth on both sides?

No. Many entries explicitly state smooth release faces on both sides, but separately marked brown textured-weave alternatives are also listed. Select an entry that explicitly identifies the required face construction.

What material is used for Smooth Double Face PTFE Release Cloth?

The specified material is PTFE-coated fiberglass fabric.

What should I include in a quotation request?

For model HT-060, send the selected SKU and order quantity. Include double-smooth or textured-weave construction, color, thickness, width and length. Pricing is by quotation for the selected specification and quantity.
