PTFE Heat Sealing Release Cloth

PTFE release cloth for cut sealing-bar covers and replacement non-stick layers on packaging equipment.

  • Cut sealing-bar cover format
  • Non-adhesive release cloth
  • White equipment liner stock
Request a Quote -> Custom Size ->
Product Overview

PTFE Heat Sealing Release Cloth Supplier

A sealing-bar cover must lie flat, cover the contact area and fit the bar's fixing method. Specify the existing cloth thickness and the finished strip outline when replacing it. The cloth supplies release and separation within the machine; the heater, pressure and dwell settings still determine the seal.

Technical Specifications

Product Parameters

Material and construction PTFE-coated fiberglass fabric
Standard formats 0.08 mm thickness; 0.13 mm thickness; 0.18 mm thickness; 4 listed formats
Ordering model HT-080
Price Request a Quote
Construction options Cut sealing-bar cover format; Non-adhesive release cloth; White equipment liner stock
MOQ Quoted by the selected supply unit and quantity
Packaging Rolls protected on cores; cut sheets separated and packed flat or rolled to suit the material.
Models & Available Formats

Available Stock Specifications

The following reference formats and drawing-based configurations are available for quotation. Specify the finished dimensions and quantity in your inquiry.

Request Model Quote
SKU / Model Available Specification Material Supply Format Price
HT-080-REF01 0.08 mm thickness PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-080-REF02 0.13 mm thickness PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-080-REF03 0.18 mm thickness PTFE-coated fiberglass fabric Roll / cut length Request a Quote
HT-080-REF04 0.25 mm thickness PTFE-coated fiberglass fabric Roll / cut length Request a Quote

Note: Each line identifies a specification for quotation. Pricing covers the selected format, quantity, packing and delivery schedule.

Send specification for quotation ->
Applications

Typical Applications

  • Impulse sealing bar covers
  • Packaging release layers
  • Bag-making equipment liners
Customization Options

PTFE Heat Sealing Release Cloth Ordering Options

Send Requirement ->

For PTFE Heat Sealing Release Cloth, specify finished thickness, width, cut outline and the required quantity.

  • Dimensions and construction Specify finished thickness, width, cut outline and the required quantity.
  • Material PTFE-coated fiberglass fabric
  • Supply and packing Rolls protected on cores; cut sheets separated and packed flat or rolled to suit the material.
FAQ

Frequently Asked Questions

Which thicknesses are listed for PTFE heat-sealing release cloth?

Four reference thicknesses are listed: 0.08, 0.13, 0.18 and 0.25 mm. The entries do not fix a width or length, so include the sealing-bar cover dimensions with the chosen gauge.

Is this sealing release cloth adhesive-backed?

The construction options identify non-adhesive release cloth and white equipment liner stock. An adhesive backing is not named for these reference entries.

What material is used for PTFE Heat Sealing Release Cloth?

The specified material is PTFE-coated fiberglass fabric.

What should I include in a quotation request?

For model HT-080, send the selected SKU and order quantity. Include cloth thickness, cover width and length, and non-adhesive construction. Pricing is by quotation for the selected specification and quantity.
