Polyester Monofilament Screening Mesh

Polyester monofilament mesh in coarse through fine counts for screening, liquid straining and tensioned printing frames.

  • 20–600 mesh catalogue options
  • 1000 and 1270 mm common widths
  • 3500 mm-wide 400-mesh option
Request a Quote -> Custom Size ->
Product Overview

Polyester Monofilament Screening Mesh Supplier

Polyester monofilament provides an orderly woven surface that can be cut or tensioned. Wide stock serves larger frames; heavier-thread coarse grades suit more demanding handling. Mesh count and yarn diameter work together to set opening size, flow and the amount of material passing through a printing screen.

Technical Specifications

Product Parameters

Material and construction PET polyester monofilament
Standard formats 20 mesh, heavy yarn × 1 m width; 30 mesh, heavy yarn × 1 m width; 40 mesh, heavy yarn × 1 m width; 20 listed formats
Ordering model HT-017
Price Request a Quote
Construction options 20–600 mesh catalogue options; 1000 and 1270 mm common widths; 3500 mm-wide 400-mesh option
MOQ Quoted by the selected supply unit and quantity
Packaging Rolls protected on cores; cut sheets separated and packed flat or rolled to suit the material.
Models & Available Formats

Available Stock Specifications

Choose a listed specification and quantity for a quotation. Dimensions, material construction and pack formats are shown by model.

Request Model Quote
SKU / Model Available Specification Material Supply Format Price
HT-017-001 20 mesh, heavy yarn × 1 m width PET polyester monofilament Roll / cut length Request a Quote
HT-017-002 30 mesh, heavy yarn × 1 m width PET polyester monofilament Roll / cut length Request a Quote
HT-017-003 40 mesh, heavy yarn × 1 m width PET polyester monofilament Roll / cut length Request a Quote
HT-017-004 60 mesh, heavy yarn × 1 m width PET polyester monofilament Roll / cut length Request a Quote
HT-017-005 80 mesh, heavy yarn × 1 m width PET polyester monofilament Roll / cut length Request a Quote
HT-017-006 100 mesh, heavy yarn × 1 m width PET polyester monofilament Roll / cut length Request a Quote
HT-017-007 80 mesh × 1.27 m width PET polyester monofilament Roll / cut length Request a Quote
HT-017-008 100 mesh × 1.27 m width PET polyester monofilament Roll / cut length Request a Quote
HT-017-009 120 mesh × 1.27 m width PET polyester monofilament Roll / cut length Request a Quote
HT-017-010 150 mesh × 1.27 m width PET polyester monofilament Roll / cut length Request a Quote
HT-017-011 160 mesh × 1.27 m width PET polyester monofilament Roll / cut length Request a Quote
HT-017-012 180 mesh × 1.27 m width PET polyester monofilament Roll / cut length Request a Quote
HT-017-013 200 mesh × 1.27 m width PET polyester monofilament Roll / cut length Request a Quote
HT-017-014 250 mesh × 1.27 m width PET polyester monofilament Roll / cut length Request a Quote
HT-017-015 300 mesh × 1.27 m width PET polyester monofilament Roll / cut length Request a Quote
HT-017-016 350 mesh × 1.27 m width PET polyester monofilament Roll / cut length Request a Quote
HT-017-017 400 mesh × 3.5 m extra-wide PET polyester monofilament Roll / cut length Request a Quote
HT-017-018 450 mesh × 1.27 m PET polyester monofilament Roll / cut length Request a Quote
HT-017-019 500 mesh × 1.27 m PET polyester monofilament Roll / cut length Request a Quote
HT-017-020 600 mesh × 1.27 m PET polyester monofilament Roll / cut length Request a Quote

Note: Each line identifies a specification for quotation. Pricing covers the selected format, quantity, packing and delivery schedule.

Send specification for quotation ->
Applications

Typical Applications

  • Liquid straining
  • Screen printing frames
  • Fine powder screening
Customization Options

Polyester Monofilament Screening Mesh Ordering Options

Send Requirement ->

For Polyester Monofilament Screening Mesh, specify mesh count or opening, wire or yarn diameter, panel dimensions and edge finish.

  • Dimensions and construction Specify mesh count or opening, wire or yarn diameter, panel dimensions and edge finish.
  • Material PET polyester monofilament
  • Supply and packing Rolls protected on cores; cut sheets separated and packed flat or rolled to suit the material.
FAQ

Frequently Asked Questions

Which roll widths are listed for polyester screening mesh?

The table lists 1 m-wide heavy-yarn formats at selected 20–100 mesh counts, many 1.27 m-wide formats from 80 to 600 mesh, and a 400-mesh extra-wide entry at 3.5 m. Width depends on the selected mesh construction.

Are heavy-yarn and standard polyester mesh entries separate?

Yes. For example, 80-mesh and 100-mesh entries include a 1 m-wide heavy-yarn option and a separate 1.27 m-wide option. Select the full mesh-count, yarn-description and width entry.

What material is used for Polyester Monofilament Screening Mesh?

The specified material is PET polyester monofilament.

What should I include in a quotation request?

For model HT-017, send the selected SKU and order quantity. Include mesh count, yarn construction, width and required cut length. Pricing is by quotation for the selected specification and quantity.
